ClimaTek Gas Range Oven Stove Flat Ignitor Igniter Replaces Tappan White Westinghouse # 316489404
1 product review

Price: $16.95

Quantity:

Product Description


SPECS:
This igniter's amperage range is 3.3 - 3.6. Used with 3.2 to 3.5 amp rated gas safety valves. Includes: high temperature stainless steel shield high temperature MGT wire leads and high temperature ceramic wire nuts to wire into original harness. Replaces long and short ignitors. Be careful not to drop your new ignitor; ignitors are fragile and will break easily.
COMPATIBLE WITH THESE BRANDS:
Frigidaire Electrolux Franklin Gibson White-Westinghouse Westinghouse Tappan Kelvinator Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
The oven igniter, also called a glow bar, heats up the bimetal switch and causes the oven to ignite the gas fed to the burners. A common issue when the oven fails to ignite is a faulty glow bar. If the oven does not start within 90 seconds, the glow bar is likely the issue. Do not be fooled if the glow bar turns red. If it does not reach the appropriate temperature, the oven will not light. If your ignitor uses a connector on the end, reuse the connector from the old ignitor. Use your wire cutters to cut the wires on the old ignitor several inches above the connector. Strip the ends of the wires with a wire stripper. Place the end of a wire on the connector next to the end of a wire on your new ignitor. Use a ceramic wire nut to twist and hold the wires together. Your wires are not color coded, so it does not matter which wires are connected together. Your old ignitor can get very hot even if it doesn't ignite the burner tube.
REPLACES PART NUMBERS:
316489404
USED ON MODELS:
79071342704 79071342705 79071342706 79071343706 79071343707 79071343708 79071343709 79071349704 79071349705 79071349706 79071362705 79071362706 79071362707 79071363708 79071363709 7907136370A 7907136370B 79071369705 79071369706 79071369707 79071382705 79071382706 79071382707 79071382708 79071383707 79071383708 79071383709 7907138370A 79071384705 79071384706 79071384707 79071384708 79071389705 79071389706 79071389707 79071389708 79072301010 79072301011 79072302010 79072302011 79072303010 79072303011 79072309010 79072309011 79072312010 79072312011 79072312012 79072313010 79072313011 79072313012 79072319010 79072319011 79072319012 79072333010 79072333011 79072333012 79072402012 79072402013 79072403011 79072403012 79072404012 79072404013 79072408012 79072408013 79072409012 79072409013 79072502010 79072502011 79072503010 79072503011 79072509010 79072509011 79072602010 79072602011 79072603010 79072603011 79072609010 79072609011 79072702010 79072702011 79072702012 79072703010 79072703011 79072703012 79072704010 79072704011 79072704012 79072709010 79072709011 79072709012 79072802010 79072802011 79072802012 79072803010 79072803011 79072803012 79072809010 79072809011 79072809012 79072902010 79072902011 79072902012 79072903010 79072903011 79072903012 79072904010 79072904011 79072904012 79072909010 79072909011 79072909012 79077433900 79077433901 79077433902 79077433903 79077442802 79077442803 79077442804 79077442805 79077443803 79077444802 79077444803 79077444804 79077444805 79077449802 79077449803 79077449804 79077449805 79077462802 79077462803 79077462804 79077462805 79077463803 79077463804 79077463806 79077464802 79077464803 79077464804 79077464805 79077469802 79077469803 79077469804 79077469805 79077482802 79077482803 79077482804 79077482805 79077483804 79077483805 79077483806 79077483807 79077484802 79077484803 79077484804 79077484805 79077489802 79077489803 79077489804 79077489805 79077492803 79077493804 79077493805 79077493806 79077499803 79077512803 79077512804 79077512805 79077512806 79077513805 79077513806 79077513807 79077513808 79077519803 79077519804 79077519805 79077519806 79077532802 79077532804 79077532805 79077532806 79077533802 79077533803 79077533804 79077533805 79077533806 79077533807 79077539802 79077539804 79077539805 79077539806 79077543802 79077543803 79077543804 79077543805 79077543806 79077543807 79077563900 79077563901 79077563902 79077563903 79078302010 79078302011 79078302012 79078303010 79078303011 79078303012 79078309010 79078309011 79078309012 79078402010 79078402011 79078402012 79078403010 79078403011 79078403012 79078409010 79078409011 79078409012 79078413010 79078413011 79078413012 79078530606 79078530607 79078530608 79078530609 79078531606 79078531607 79078531608 79078531609 79078532704 79078532705 79078532706 79078532707 79078541606 79078542704 79078618507 79078618508 79078618509 7907861850A 7907861850B 79078852606 79078853607 79078859606 79078882900 79078882902 79078882903 79078882904 79078883900 79078883901 79078883902 79078883903 79078889900 79078889902 79078889903 79078889904 79078893900 79078893902 79078893903 79078893904 79079653705 79079653706 79079653707 79079653708 79079653709 7907965370A BGGF3031KBA BGGF3031KBB BGGF3031KBC BGGF3031KBD BGGF3031KBE BGGF3031KBF BGGF3031KBG BGGF3031KBH BGGF3031KWA BGGF3031KWB BGGF3031KWC BGGF3031KWD BGGF3031KWE BGGF3031KWF BGGF3031KWG BGGF3031KWH BGGF3041KFA BGGF3041KFB BGGF3041KFC BGGF3041KFD BGGF3041KFE BGGF3042KFA BGGF3042KFB BGGF3042KFC BGGF3042KFD BGGF3042KFE BGGF3042KFF BGGF3042KFG BGGF3042KFH BGGF3042KFJ BGGF3042KFK BGGF3042KFM BGGF3042KFN CEI30GF5GSD CEI30GF5GSE CEI30GF5GSF CEI30GF5GSG CEI30GF5GSH CEW30GF6GBD CEW30GF6GSE CEW30GF6GSF CEW30GF6GSG CEW30GF6GSH CEW30GF6GSJ CEW30GF6GWD CFGF3023LWA CFGF3023LWB CFGF3023LWC CFGF3053LSA CFGF3053LSB CFGF3053LSC CFGF3053LSD CFGF3053LSE CFGF368GBE CFGF368GBF CFGF368GBG CFGF368GCF CFGF368GCG CFGF368GCH CFGF368GCJ CFGF368GME CFGF368GMG CFGF368GMH CFGF368GSE CFGF368GSF CFGF368GSG CFGFL87GCE CGGF3032KBB CGGF3032KBD CGGF3032KBG CGGF3032KBJ CGGF3032KWB CGGF3032KWD CGGF3032KWG CGGF3032KWJ CGGF3042KFB CGGF3042KFD CGGF3042KFE CGGF3042KFF CGGF3042KFG CGGF3042KFH CGGF3042KFJ CGGF3042KFK CGGF3054KBB CGGF3054KBC CGGF3054KBF CGGF3054KBK CGGF3054KFB CGGF3054KFC CGGF3054KFE CGGF3054KFG CGGF3054KFH CGGF3054KFJ CGGF3054KFK CGGF3054KWB CGGF3054KWC CGGF3054KWF CGGF3054KWH CGGF3054KWK CGGF3054MBA CGGF3054MFA CGGF3054MFB CGGF3054MWA CGGF3056KFA CGGF3056KFB CGGF3056KFC CGGF3056KFD CGGF3056KFE CGGF3056KFG CGGF3056KFH CGGF3056KFJ CGGF3056KFK CGGF3056KFM CGGF3056KFN CGGF3076KBD CGGF3076KBG CGGF3076KBH CGGF3076KBJ CGGF3076KBK CGGF3076KWD CGGF3076KWG CGGF3076KWH CGGF3076KWJ CGGF3076KWK CGLGF386GSD CGLGF389GBD CGLGF389GSD CGLGFZ86GCE CPGF3081KFA CPGF3081KFB CPGF3081KFD CPGF3081KFG CPGF3081KFH CPGF3081KFK CPGF3081KFM CPGF3081KFM CPLGFZ97GCF DGGF3032KBA DGGF3032KBB DGGF3032KBC DGGF3032KBD DGGF3032KBE DGGF3032KBF DGGF3032KBG DGGF3032KBH DGGF3032KBJ DGGF3032KWA DGGF3032KWB DGGF3032KWC DGGF3032KWD DGGF3032KWE DGGF3032KWF DGGF3032KWG DGGF3032KWH DGGF3032KWJ DGGF3042KFA DGGF3042KFB DGGF3042KFC DGGF3042KFD DGGF3042KFE DGGF3042KFF DGGF3042KFG DGGF3042KFH DGGF3042KFJ DGGF3042KFK DGGF3054KFA DGGF3054KFB DGGF3054KFC DGGF3054KFE DGGF3054KFF DGGF3054KFG DGGF3054KFH DGGF3054KFJ DGGF3054KFK DGGF3054KFM EI30GF55GBB EI30GF55GBC EI30GF55GSD EI30GF55GSE EI30GF55GSF EI30GF55GSG EI30GF55GSH EI30GF55GWB EI30GF55GWC EW30GF65GBD EW30GF65GBE EW30GF65GSE EW30GF65GSF EW30GF65GSG EW30GF65GSH EW30GF65GSJ EW30GF65GSK EW30GF65GWD EW30GF65GWE EW3LGF65GBD EW3LGF65GSE EW3LGF65GSF EW3LGF65GSG EW3LGF65GSH EW3LGF65GSJ EW3LGF65GWD FFGF3021LBA FFGF3021LBB FFGF3021LBC FFGF3021LWA FFGF3021LWB FFGF3021LWC FFGF3023LBA FFGF3023LBB FFGF3023LBC FFGF3023LMA FFGF3023LMB FFGF3023LMC FFGF3023LQA FFGF3023LQB FFGF3023LQC FFGF3023LSA FFGF3023LSC FFGF3023LWA FFGF3023LWB FFGF3023LWC FFGF3027LBA FFGF3027LBB FFGF3027LSA FFGF3027LSB FFGF3027LSC FFGF3027LWA FFGF3027LWB FFGF3051LSA FFGF3051LSB FFGF3051LSC FFGF3051LSD FFGF3051LSE FFGF3051LSF FFGF3051LSF FFGF3053LSA FFGF3053LSB FFGF3053LSC FFGF3053LSD FFGF3053LSE FFGF3053LSF FGF364KCA FGF364KCB FGF364KCC FGF364KCD FGF364KCF FGF364KCG FGF364KSA FGF368GBG FGF368GBH FGF368GBJ FGF368GBK FGF368GCG FGF368GCH FGF368GCJ FGF368GCK FGF368GCM FGF368GCN FGF368GCP FGF368GMF FGF368GMG FGF368GMH FGF368GMJ FGF368GMK FGF368GMN FGF368GMP FGF368GMR FGF368GQG FGF368GQH FGF368GQJ FGF368GSG FGF368GSH FGF368GSJ FGF382HBD FGF382HCG FGF382HCH FGF382HCJ FGF382HSE FGFB66ECP FGFB66ECR FGFB66ECS FGFB79GBF FGFB79GCH FGFB79GSF FGFBZ90GCH FGFL67HBE FGFL67HBF FGFL67HBG FGFL67HBH FGFL67HBJ FGFL67HCE FGFL67HCF FGFL67HSE FGFL67HSF FGFL67HSG FGFL67HSH FGFL67HSJ FGFL79GBF FGFL79GCH FGFL79GQF FGFL79GSF FGFL87GSH FGFLMC55GCH FGFLMC55GCJ FGFLMC55GCK FGFLZ87GCH FGGF3031KBA FGGF3031KBB FGGF3031KBC FGGF3031KBD FGGF3031KBE FGGF3031KBF FGGF3031KBG FGGF3031KBH FGGF3031KBJ FGGF3031KQA FGGF3031KQB FGGF3031KQC FGGF3031KQD FGGF3031KQE FGGF3031KQF FGGF3031KQG FGGF3031KQH FGGF3031KQJ FGGF3031KWA FGGF3031KWB FGGF3031KWC FGGF3031KWD FGGF3031KWE FGGF3031KWF FGGF3031KWG FGGF3031KWH FGGF3031KWJ FGGF3032KBA FGGF3032KBB FGGF3032KBC FGGF3032KBD FGGF3032KBE FGGF3032KBF FGGF3032KBG FGGF3032KBH FGGF3032KBJ FGGF3032KWA FGGF3032KWB FGGF3032KWC FGGF3032KWD FGGF3032KWE FGGF3032KWF FGGF3032KWG FGGF3032KWH FGGF3032KWJ FGGF3041KFA FGGF3041KFB FGGF3041KFC FGGF3041KFD FGGF3041KFE FGGF3041KFF FGGF3041KFG FGGF3041KFH FGGF3041KFJ FGGF3041KFK FGGF3042KFA FGGF3042KFB FGGF3042KFC FGGF3042KFD FGGF3042KFE FGGF3042KFF FGGF3042KFG FGGF3042KFH FGGF3042KFJ FGGF3042KFK FGGF3054KBA FGGF3054KBB FGGF3054KBC FGGF3054KBD FGGF3054KBE FGGF3054KBF FGGF3054KBG FGGF3054KBH FGGF3054KBJ FGGF3054KBK FGGF3054KFA FGGF3054KFB FGGF3054KFC FGGF3054KFD FGGF3054KFE FGGF3054KFF FGGF3054KFG FGGF3054KFH FGGF3054KFJ FGGF3054KFK FGGF3054KWA FGGF3054KWB FGGF3054KWC FGGF3054KWD FGGF3054KWE FGGF3054KWF FGGF3054KWG FGGF3054KWH FGGF3054KWJ FGGF3054KWK FGGF3054MBA FGGF3054MFA FGGF3054MFB FGGF3054MWA FGGF3056KFA FGGF3056KFB FGGF3056KFC FGGF3056KFD FGGF3056KFE FGGF3056KFF FGGF3056KFG FGGF3056KFH FGGF3056KFJ FGGF3056KFK FGGF3056KFM FGGF3056KFN FGGF305MKFA FGGF305MKFB FGGF305MKFE FGGF305MKFF FGGF305MKFG FGGF305MKFH FGGF305MKFJ FGGF305MKFK FGGF305MKFM FGGF3076KBA FGGF3076KBB FGGF3076KBC FGGF3076KBD FGGF3076KBE FGGF3076KBF FGGF3076KBG FGGF3076KBH FGGF3076KBJ FGGF3076KBK FGGF3076KWA FGGF3076KWB FGGF3076KWC FGGF3076KWD FGGF3076KWE FGGF3076KWF FGGF3076KWH FGGF3076KWJ FGGF3076KWK FPGF3081KFA FPGF3081KFB FPGF3081KFC FPGF3081KFD FPGF3081KFE FPGF3081KFF FPGF3081KFG FPGF3081KFH FPGF3081KFJ FPGF3081KFK FPGF3081KFM GLGF376DBN GLGF376DBR GLGF376DSN GLGF376DSR GLGF386DBM GLGF386DQM GLGF386DSM GLGF389GBG GLGF389GSG GLGFZ386FCJ LFGF3022LSA LFGF3022LSB LFGF3022LSC LFGF3022LSD LFGF3022LWA LFGF3022LWC LFGF3027LBA LFGF3027LBB LFGF3027LSA LFGF3027LSB LFGF3027LSC LFGF3027LWA LFGF3027LWB LGGF3032KBA LGGF3032KBB LGGF3032KBC LGGF3032KBD LGGF3032KBE LGGF3032KBF LGGF3032KBG LGGF3032KBH LGGF3032KBJ LGGF3032KMA LGGF3032KMB LGGF3032KMC LGGF3032KQA LGGF3032KQB LGGF3032KQC LGGF3032KQD LGGF3032KQE LGGF3032KQF LGGF3032KQG LGGF3032KQH LGGF3032KQJ LGGF3032KWA LGGF3032KWB LGGF3032KWC LGGF3032KWD LGGF3032KWE LGGF3032KWF LGGF3032KWG LGGF3032KWH LGGF3032KWJ LGGF3033KBA LGGF3033KBD LGGF3033KWA LGGF3033KWD LGGF3033KWE LGGF3033KWF LGGF3033KWG LGGF3042KBA LGGF3042KFA LGGF3042KFB LGGF3042KFC LGGF3042KFD LGGF3042KFE LGGF3042KFF LGGF3042KFG LGGF3042KFH LGGF3042KFJ LGGF3042KFK LGGF3042KWA LGGF3043KFA LGGF3043KFC LGGF3043KFD LGGF3043KFE LGGF3043KFF LGGF3043KFG LGGF3043KFH LGGF3043KFJ LGGF3043KFK LGGF3043KFM LGGF3043KFN LGGF3044LBA LGGF3044LBA LGGF3044LFA LGGF3044LFB LGGF3044LFC LGGF3044LFD LGGF3044LFE LGGF3044LQA LGGF3044LQA LGGF3044LWA LGGF3044LWA LGGF305MKFA LGGF305MKFB LGGF305MKFC LGGF305MKFD LGGF305MKFE LGGF305MKFF LGGF305MKFG LGGF305MKFH LGGF305MKFJ LGGF305MKFK LGGF305MKFM LGLF305MMFA LPGF3091KSA LPGF3091KSB LPGF3091KSD LPGF3091KSE LPGF3091KSF LPGF3091KSG LPGF3091KSH LPGF3091KSJ PLGFZ390ECK PLGFZ397GCH TGF351ESP WWGF3004KWC WWGF3004KWE WWGF3004KWF WWGF3004KWG


Product Reviews

Write Review

  1. Oven wasn't lighting 4 Star Review

    Posted by on 11th Feb 2016

    Oven burner wasn't coming on even tho old igniter was heating up and glowing orange. Replaced the igniter in less than fifteen minutes and now oven is working perfectly. Service and delivery was excellent, item was shipped in padded box same day I ordered it, I chose USPS Priority and it was delivered on time in two days.
    I will definitely use this site again should the need arise to repair my stove in the future.
