ClimaTek Gas Oven Stove Flat Ignitor Igniter Replaces GE General Electric # WB13T10001 WB13K10008

Price: $16.95

Quantity:

Product Description


SPECS:
This igniter's amperage range is 3.3 - 3.6. Used with 3.2 to 3.5 amp rated gas safety valves. Includes: high temperature stainless steel shield high temperature MGT wire leads and high temperature ceramic wire nuts to wire into original harness. Replaces long and short ignitors. Be careful not to drop your new ignitor; ignitors are fragile and will break easily.
COMPATIBLE WITH THESE BRANDS:
GE General Electric Hotpoint RCA Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
The oven igniter, also called a glow bar, heats up the bimetal switch and causes the oven to ignite the gas fed to the burners. A common issue when the oven fails to ignite is a faulty glow bar. If the oven does not start within 90 seconds, the glow bar is likely the issue. Do not be fooled if the glow bar turns red. If it does not reach the appropriate temperature, the oven will not light. If your ignitor uses a connector on the end, reuse the connector from the old ignitor. Use your wire cutters to cut the wires on the old ignitor several inches above the connector. Strip the ends of the wires with a wire stripper. Place the end of a wire on the connector next to the end of a wire on your new ignitor. Use a ceramic wire nut to twist and hold the wires together. Your wires are not color coded, so it does not matter which wires are connected together. Your old ignitor can get very hot even if it doesn't ignite the burner tube.
REPLACES PART NUMBERS:
WB13T10001 WB13K10008
USED ON MODELS:
JGSP22GEV3BB JGSP23BEY1BB JGSP23BEY2BB JGSP23BEY3BB JGSP23BEY4BB JGSP23BEY5BB JGSP23CEY1CC JGSP23WEV5WW JGSP23WEV6WW JGSP23WEY1WW JGSP23WEY2WW JGSP23WEY3WW JGSP23WEY5WW JGSP23WEY6WW JGSP23WEY7WW JGSP32GEV2BB JGSP32GEV3BB JGSP33WEV3WW JGSP33WEV4WW JGSP33WEV5WW JGSP33WEV6WW JGSP33WEV7WW JGSP44AEV2AA JGSP44AEV3AA JGSP44AEY1AA JGSP44BEY1BB JGSP44BEY2BB JGSP44BEY3BB JGSP44CEY1CC JGSP44WEY1WW JGSP44WEY2WW JGSP44WEY3WW JGSP44WEY4WW JGSP44WEY6WW JGSP44WEY7WW JGSP44WEY8WW
