ClimaTek Gas Range Oven Stove Flat Ignitor Igniter Replaces GE General Electric # WB2X8605 WB02X8605

Price: $14.95

Quantity:

Product Description


SPECS:
This igniter's amperage range is 3.3 - 3.6. Used with 3.2 to 3.5 amp rated gas safety valves. Includes: high temperature stainless steel shield high temperature MGT wire leads and high temperature ceramic wire nuts to wire into original harness. Replaces long and short ignitors. Be careful not to drop your new ignitor; ignitors are fragile and will break easily.
COMPATIBLE WITH THESE BRANDS:
GE General Electric Hotpoint RCA Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
The oven igniter, also called a glow bar, heats up the bimetal switch and causes the oven to ignite the gas fed to the burners. A common issue when the oven fails to ignite is a faulty glow bar. If the oven does not start within 90 seconds, the glow bar is likely the issue. Do not be fooled if the glow bar turns red. If it does not reach the appropriate temperature, the oven will not light. If your ignitor uses a connector on the end, reuse the connector from the old ignitor. Use your wire cutters to cut the wires on the old ignitor several inches above the connector. Strip the ends of the wires with a wire stripper. Place the end of a wire on the connector next to the end of a wire on your new ignitor. Use a ceramic wire nut to twist and hold the wires together. Your wires are not color coded, so it does not matter which wires are connected together. Your old ignitor can get very hot even if it doesn't ignite the burner tube.
REPLACES PART NUMBERS:
WB2X8605 WB02X8605
USED ON MODELS:
ZDP36L4DD1SS ZDP36L4DD2SS ZDP36L4DH1SS ZDP36L4DH2SS ZDP36L4DH3SS ZDP36L4DH4SS ZDP36L4DH5SS ZDP36L4DH6SS ZDP36L4DH7SS ZDP36L4DWSS ZDP36L4RD1SS ZDP36L4RD2SS ZDP36L4RH1SS ZDP36L4RH2SS ZDP36L4RH3SS ZDP36L4RH4SS ZDP36L4RH5SS ZDP36L4RWSS ZDP36N4DD1SS ZDP36N4DD2SS ZDP36N4DH1SS ZDP36N4DH2SS ZDP36N4DH3SS ZDP36N4DH4SS ZDP36N4DH5SS ZDP36N4DH6SS ZDP36N4DH7SS ZDP36N4DWSS ZDP36N4RD1SS ZDP36N4RD2SS ZDP36N4RH1SS ZDP36N4RH2SS ZDP36N4RH3SS ZDP36N4RH4SS ZDP36N4RH5SS ZDP36N4RWSS ZDP48L4GD1SS ZDP48L4GD2SS ZDP48L4GH1SS ZDP48L4GH2SS ZDP48L4GH3SS ZDP48L4GH4SS ZDP48L4GH5SS ZDP48L4GWSS ZDP48L6DD1SS ZDP48L6DD2SS ZDP48L6DH1SS ZDP48L6DH2SS ZDP48L6DH3SS ZDP48L6DH4SS ZDP48L6DH5SS ZDP48L6DH6SS ZDP48L6DH7SS ZDP48L6DWSS ZDP48L6RD1SS ZDP48L6RD2SS ZDP48L6RH1SS ZDP48L6RH2SS ZDP48L6RH3SS ZDP48L6RH4SS ZDP48L6RH5SS ZDP48L6RWSS ZDP48N4GD1SS ZDP48N4GD2SS ZDP48N4GH1SS ZDP48N4GH2SS ZDP48N4GH3SS ZDP48N4GH4SS ZDP48N4GH5SS ZDP48N4GWSS ZDP48N6DD1SS ZDP48N6DD2SS ZDP48N6DDSS ZDP48N6DH1SS ZDP48N6DH2SS ZDP48N6DH3SS ZDP48N6DH4SS ZDP48N6DH5SS ZDP48N6DH6SS ZDP48N6DH7SS ZDP48N6DWSS ZDP48N6RD1SS ZDP48N6RD2SS ZDP48N6RDSS ZDP48N6RH1SS ZDP48N6RH2SS ZDP48N6RH3SS ZDP48N6RH4SS ZDP48N6RH5SS ZDP48N6RWSS ZGS30L4ASS ZGS30N4ASS ZGU36L4DD1SS ZGU36L4DH1SS ZGU36L4DH2SS ZGU36L4DH3SS ZGU36L4DH4SS ZGU36L4DH5SS ZGU36L4DYSS ZGU36L4RD1SS ZGU36L4RD2SS ZGU36L4RH1SS ZGU36L4RH2SS ZGU36L4RH3SS ZGU36L4RH4SS ZGU36L4RH5SS ZGU36L4RYSS ZGU36N4DD1SS ZGU36N4DH1SS ZGU36N4DH2SS ZGU36N4DH3SS ZGU36N4DH4SS ZGU36N4DH5SS ZGU36N4DYSS ZGU36N4RD1SS ZGU36N4RD2SS ZGU36N4RH1SS ZGU36N4RH2SS ZGU36N4RH3SS ZGU36N4RH4SS ZGU36N4RH5SS ZGU36N4RYSS ZGU48L4GD1SS ZGU48L4GD2SS ZGU48L4GH1SS ZGU48L4GH2SS ZGU48L4GH3SS ZGU48L4GH4SS ZGU48L4GH5SS ZGU48L4GWSS ZGU48L6DD1SS ZGU48L6DH1SS ZGU48L6DH2SS ZGU48L6DH3SS ZGU48L6DH4SS ZGU48L6DH5SS ZGU48L6DWSS ZGU48L6RD1SS ZGU48L6RD2SS ZGU48L6RH1SS ZGU48L6RH2SS ZGU48L6RH3SS ZGU48L6RH4SS ZGU48L6RH5SS ZGU48L6RWSS ZGU48N4GD1SS ZGU48N4GD2SS ZGU48N4GH1SS ZGU48N4GH2SS ZGU48N4GH3SS ZGU48N4GH4SS ZGU48N4GH5SS ZGU48N4GWSS ZGU48N6DD1SS ZGU48N6DH1SS ZGU48N6DH2SS ZGU48N6DH3SS ZGU48N6DH4SS ZGU48N6DH5SS ZGU48N6DWSS ZGU48N6RD1SS ZGU48N6RD2SS ZGU48N6RH1SS ZGU48N6RH2SS ZGU48N6RH3SS ZGU48N6RH4SS ZGU48N6RH5SS ZGU48N6RWSS
