- ClimaTek Gas Oven Flat Ignitor Igniter Replaces GE Hotpoint Kenmore # WB16K10043 WB16K27 WB16K0027
Product Description
SPECS:
This igniter's amperage range is 3.3 - 3.6. Used with 3.2 to 3.5 amp rated gas safety valves. Includes: high temperature stainless steel shield high temperature MGT wire leads and high temperature ceramic wire nuts to wire into original harness. Replaces long and short ignitors. Be careful not to drop your new ignitor; ignitors are fragile and will break easily.
COMPATIBLE WITH THESE BRANDS:
GE General Electric Hotpoint RCA Sears Kenmore
OEM / AFTERMARKET:
Aftermarket
DESCRIPTION:
The oven igniter, also called a glow bar, heats up the bimetal switch and causes the oven to ignite the gas fed to the burners. A common issue when the oven fails to ignite is a faulty glow bar. If the oven does not start within 90 seconds, the glow bar is likely the issue. Do not be fooled if the glow bar turns red. If it does not reach the appropriate temperature, the oven will not light. If your ignitor uses a connector on the end, reuse the connector from the old ignitor. Use your wire cutters to cut the wires on the old ignitor several inches above the connector. Strip the ends of the wires with a wire stripper. Place the end of a wire on the connector next to the end of a wire on your new ignitor. Use a ceramic wire nut to twist and hold the wires together. Your wires are not color coded, so it does not matter which wires are connected together. Your old ignitor can get very hot even if it doesn't ignite the burner tube.
REPLACES PART NUMBERS:
WB16K10043 WB16K27 WB16K0027
USED ON MODELS:
36261111699 36261118699 36261120101 36261120102 36261120103 36261120104 36261121890 36261121891 36261121892 36261121893 36261121894 36261121895 36261121896 36261128890 36261128891 36261128892 36261128893 36261128894 36261128895 36271112000 36271112001 36271117000 36271117001 36271161691 36271168691 36271171890 36271171891 36271178890 36271178891 36271330200 36271330201 36271330202 36271331200 36271331201 36271331202 36271332200 36271332201 36271332202 36271351790 36271358790 36271661691 36271665691 36271668691 36271671890 36271671891 36271675890 36271675891 36271678890 36271678891 36271751694 36271758694 36271761890 36271761891 36271768890 36271768891 36272181890 36272181891 36272188890 36272188891 36272191890 36272191891 36272191892 36272198890 36272198891 36272198892 36272201890 36272201891 36272201892 36272201893 36272205891 36272205892 36272205893 36272206891 36272206892 36272206893 36272208891 36272208892 36272208893 36272210101 36272210102 36272211101 36272211102 36272212101 36272212102 36272214101 36272214102 36272220200 36272220201 36272220202 36272220203 36272220204 36272221200 36272221201 36272221202 36272221203 36272221204 36272222200 36272222201 36272222202 36272222203 36272222204 36272224200 36272224201 36272224202 36272224203 36272224204 36272230200 36272230201 36272230202 36272230203 36272230204 36272231200 36272231201 36272231202 36272231203 36272231204 36272232200 36272232201 36272232202 36272232203 36272232204 36272239200 36272239201 36272239202 36272239203 36272239204 36272281890 36272281891 36272285890 36272285891 36272286890 36272286891 36272288890 36272288891 36272291790 36272295790 36272296790 36272298790 36272422200 36272422201 36272422202 36272424200 36272424201 36272424202 36272429200 36272429201 36272429202 36272751694 36272755694 36272758694 36272760101 36272761890 36272761891 36272761892 36272761893 36272765890 36272765891 36272765892 36272765893 36272768890 36272768891 36272768892 36273210200 36273210201 36273210202 36273210203 36273210204 36273210205 36273211200 36273211201 36273211202 36273211203 36273211204 36273211205 36273212200 36273212201 36273212202 36273212203 36273212204 36273212205 36273219200 36273219201 36273219202 36273219203 36273219204 36273219205 36273220200 36273220201 36273220202 36273220203 36273220204 36273220205 36273221200 36273221201 36273221202 36273221203 36273221204 36273221205 36273222200 36273222201 36273222202 36273222203 36273222204 36273222205 36273224200 36273224201 36273224202 36273224203 36273224204 36273224205 36273422200 36273422201 36273422202 36273424200 36273424201 36273424202 36273429200 36273429201 36273429202 36274220302 36274221301 36274221302 36274222302 36274224302 36275171790 36275181691 36275181692 36275188691 36275188692 36275190100 36275190101 36275191890 36275191891 36275191892 36275191893 36275191894 36275192100 36275192101 36275198890 36275198891 36275198892 36275198893 36275199100 36275199101 36275201890 36275201891 36275201892 36275201893 36275205890 36275205891 36275205892 36275205893 36275206890 36275206891 36275206892 36275206893 36275208890 36275208891 36275208892 36275208893 36275210101 36275210102 36275211101 36275211102 36275212101 36275212102 36275214101 36275214102 36275271691 36275271692 36275275691 36275275692 36275276691 36275276692 36275278691 36275278692 36275281790 36275291790 36275295790 36275296790 36275298790 JGBC17PEA1AD JGBC17PEA1WH JGBC17PEA2AD JGBC17PEA2WH JGBC17PEA3AD JGBC17PEA3WH JGBC17PEW2AD JGBC17PEW2WH JGBC20BEA1AD JGBC20BEA1CT JGBC20BEA1WH JGBC20BEA2AD JGBC20BEA2CT JGBC20BEA2WH JGBC20BEA3AD JGBC20BEA3CT JGBC20BEA3WH JGBC20BEA4WH JGBC20BEA5WH JGBC20BEH1CT JGBC20BEH1WH JGBC20BEH2CT JGBC20BEH2WH JGBC20BEW2AD JGBC20BEW2WH JGBC20CEH1CC JGBC20CEH2CC JGBC20WEA1WW JGBC20WEA2WW JGBC20WEA3WW JGBC20WEA4WW JGBC20WEA5WW JGBC20WEH1WW JGBC20WEH2WW JGBC20WEW2WW JGBS04BEA1AD JGBS04BEA1CT JGBS04BEA1WH JGBS04BEA2AD JGBS04BEA2CT JGBS04BEA2WH JGBS04BEA3AD JGBS04BEA3WH JGBS04BEA4AD JGBS04BEA4WH JGBS04BEA5AD JGBS04BEA5WH JGBS04BEA6AD JGBS04BEA6WH JGBS04BEA7WH JGBS04BEH1CT JGBS04BEH1WH JGBS04BEH2CT JGBS04BEH2WH JGBS04BEH3CT JGBS04BEH3WH JGBS04BEW2AD JGBS04BEW2WH JGBS04PEA1AD JGBS04PEA1CT JGBS04PEA1WH JGBS04PEA2AD JGBS04PEA2CT JGBS04PEA2WH JGBS04PEA3AD JGBS04PEA3CT JGBS04PEA3WH JGBS04PEA4AD JGBS04PEA4WH JGBS04PEA5AD JGBS04PEA5WH JGBS04PEA6AD JGBS04PEA6WH JGBS04PEA7WH JGBS04PEW2AD JGBS04PEW2WH JGBS07PEA1WW JGBS07PEA2WW JGBS07PEA3WW JGBS07PEA4WW JGBS07PEA5WW JGBS07PEA6WW JGBS07PEA7WW JGBS07PEH1BB JGBS07PEH1CC JGBS07PEH1WW JGBS07PEH2BB JGBS07PEH2CC JGBS07PEH2WW JGBS07PEW2WW JGBS09PEF1WW JGBS09PEH1WW JGBS09PEH2WW JGBS09PEH3WW JGBS09PEH4WW JGBS09PEH5WW JGBS10BEF1BB JGBS10BEH1BB JGBS10BEH2BB JGBS10BEH3BB JGBS10BEH4BB JGBS10BEH5BB JGBS10CEF1CC JGBS10CEH1CC JGBS10CEH2CC JGBS10CEH3CC JGBS10CEH4CC JGBS10CEH5CC JGBS10WEF1WW JGBS10WEH1WW JGBS10WEH2WW JGBS10WEH3WW JGBS10WEH4WW JGBS10WEH5WW JGBS15PEA1AD JGBS15PEA1WH JGBS15PEA2AD JGBS15PEA2WH JGBS15PEA3AD JGBS15PEA3WH JGBS15PEW1AD JGBS15PEW1WH JGBS17BEL1BB JGBS17PEA1AD JGBS17PEA1CT JGBS17PEA1WH JGBS17PEA2AD JGBS17PEA2CT JGBS17PEA2WH JGBS17PEA3AD JGBS17PEA3CT JGBS17PEA3WH JGBS17PEA4WH JGBS17PEA5WH JGBS17PEH1CT JGBS17PEH1WH JGBS17PEH2CT JGBS17PEH2WH JGBS17PEK1WW JGBS17PEK2WW JGBS17PEW2AD JGBS17PEW2WH JGBS19BEH1CT JGBS19BEH1WH JGBS19BEH2CT JGBS19BEH2WH JGBS20BEA1AD JGBS20BEA1CT JGBS20BEA1WH JGBS20BEA2AD JGBS20BEA2WH JGBS20BEA3AD JGBS20BEA3WH JGBS20BEA4AD JGBS20BEA4WH JGBS20BEA5AD JGBS20BEA5WH JGBS20BEH1CT JGBS20BEH1WH JGBS20BEH2CT JGBS20BEH2WH JGBS20BEW2AD JGBS20BEW2WH JGBS20WEA1WW JGBS20WEA2WW JGBS20WEA3WW JGBS20WEA4WW JGBS20WEA5WW JGBS20WEH1WW JGBS20WEH2WW JGBS20WEW2WW JGBS21HED1WW JGBS21HED2WW JGBS21HED3WW JGBS21HEH1WW JGBS21HEH2WW JGBS21HEH3WW JGBS21HEH4WW JGBS21HEH5WW JGBS21HEH6WW JGBS21HEH7WW JGBS21PEA1AD JGBS21PEA1WH JGBS21PEA2AD JGBS21PEA2WH JGBS21PEA3AD JGBS21PEA3WH JGBS21PEA4AD JGBS21PEA4WH JGBS21PEC1WW JGBS21PEC2WW JGBS21PEC3WW JGBS21PEW2AD JGBS21PEW2WH JGBS21PEW3AD JGBS21PEW3WH JGBS22BEA1AD JGBS22BEA1CT JGBS22BEA1WH JGBS22BEA2AD JGBS22BEA2CT JGBS22BEA2WH JGBS22BEA3AD JGBS22BEA3CT JGBS22BEA3WH JGBS22BEA4AD JGBS22BEA4WH JGBS22BEA5WH JGBS22BEA6WH JGBS22BEH1CT JGBS22BEH1WH JGBS22BEH2CT JGBS22BEH2WH JGBS22BEH3CT JGBS22BEH3WH JGBS22BEH4CT JGBS22BEH4WH JGBS22BEH5CT JGBS22BEH5WH JGBS22BEH6CT JGBS22BEH6WH JGBS22BEH7CT JGBS22BEH7WH JGBS22BEW2AD JGBS22BEW2WH JGBS22WEK1WW JGBS22WEK2WW JGBS22WEK3WW JGBS22WEK4WW JGBS23AEA1AA JGBS23AEA2AA JGBS23AEA3AA JGBS23AEA4AA JGBS23AEW2AA JGBS23AEW3AA JGBS23BEA1AD JGBS23BEA1CT JGBS23BEA1WH JGBS23BEA2AD JGBS23BEA2CT JGBS23BEA2WH JGBS23BEA3AD JGBS23BEA3CT JGBS23BEA3WH JGBS23BEA4AD JGBS23BEA4WH JGBS23BEA5WH JGBS23BEA6WH JGBS23BEH1BB JGBS23BEH2BB JGBS23BEH3BB JGBS23BEH4BB JGBS23BEH5BB JGBS23BEL1BB JGBS23BEL2BB JGBS23BEL3BB JGBS23BEW3AD JGBS23BEW3WH JGBS23BEW4AD JGBS23BEW4WH JGBS23CEA1CC JGBS23CEA2CC JGBS23CEA3CC JGBS23CEH1CC JGBS23CEH2CC JGBS23CEH3CC JGBS23CEH4CC JGBS23CEH5CC JGBS23CEL1CC JGBS23CEL2CC JGBS23CEL3CC JGBS23DEA1AD JGBS23DEA1WH JGBS23DEF1BB JGBS23DEF2BB JGBS23DEW2AD JGBS23DEW2WH JGBS23DEW3AD JGBS23DEW3WH JGBS23GEV6AD JGBS23GEV6WH JGBS23GEV7AD JGBS23GEV7WH JGBS23SEH1SS JGBS23SEH2SS JGBS23SEH3SS JGBS23SEH4SS JGBS23SEH5SS JGBS23SEL2SS JGBS23SEL3SS JGBS23WEA1WW JGBS23WEA2WW JGBS23WEA3WW JGBS23WEA4WW JGBS23WEA5WW JGBS23WEA6WW JGBS23WEH1WW JGBS23WEH2WW JGBS23WEH3WW JGBS23WEH4WW JGBS23WEH5WW JGBS23WEL1WW JGBS23WEL2WW JGBS23WEL3WW JGBS23WEW2WW JGBS23WEW3WW JGBS24BEH1CT JGBS24BEH1WH JGBS24BEH2CT JGBS24BEH2WH JGBS24BEH3CT JGBS24BEH3WH JGBS24BEH4CT JGBS24BEH4WH JGBS24BEH5CT JGBS24BEH5WH JGBS24BEH6CT JGBS24BEH6WH JGBS24BEH7CT JGBS24BEH7WH JGBS24DEK1CC JGBS24DEK2CC JGBS24DEK3CC JGBS24DEK4CC JGBS24GEK1SS JGBS24GEK2SS JGBS24GEK3SS JGBS24GEK4SS JGBS24LEK1WW JGBS24LEK2WW JGBS24LEK3WW JGBS24LEK4WW JGBS80BEL1BB JGBS80BEL2BB JGBS80SEL1SS JGBS80SEL2SS JGBS80WEL1WW JGBS80WEL2WW JGSS05BEA1BB JGSS05BEA2BB JGSS05BEA3BB JGSS05BEA4BB JGSS05BEA5BB JGSS05BEA6BB JGSS05BEA7BB JGSS05BEH1BB JGSS05BEH2BB JGSS05BEW2BB LGB126BEA1AD LGB126BEA1WH LGB126GEV3AD LGB126GEV3WH LGB128PEB1WW LGB128PEB6WW LGB146BEA1AD LGB146BEA1WH LGB146BEA2AD LGB146BEA2WH LGB146GEV4AD LGB146GEV5AD LGB146GEV5WH LGB156WEA1WW LGB156WEA2WW LGB156WEV4WW LGB156WEV5WW RGB508BEW2AD RGB508BEW2WH RGB508ET4AD RGB508ET4WH RGB508PEA1AD RGB508PEA1WH RGB508PEA2AD RGB508PEA2CT RGB508PEA2WH RGB508PEA3AD RGB508PEA3WH RGB508PEA4AD RGB508PEA4WH RGB508PEA5AD RGB508PEA5WH RGB508PEA6WH RGB508PEH1CT RGB508PEH1WH RGB508PEH2CT RGB508PEH2WH RGB508PEH3CT RGB508PEH3WH RGB524EV5AD RGB524EV5WH RGB524PEA1AD RGB524PEA1WH RGB524PEA2AD RGB524PEA2CT RGB524PEA2WH RGB524PEA3AD RGB524PEA3WH RGB524PEA4AD RGB524PEA4WH RGB524PEA5AD RGB524PEA5WH RGB524PEA6WH RGB524PEH1CT RGB524PEH1WH RGB524PEH2CT RGB524PEH2WH RGB524PEH3CT RGB524PEH3WH RGB525ET4WW RGB525PEA1WW RGB525PEA2WW RGB526ET4AD RGB526ET4WH RGB526PEA1AD RGB526PEA1CT RGB526PEA1WH RGB526PEA2AD RGB526PEA2CT RGB526PEA2WH RGB526PEA3AD RGB526PEA3CT RGB526PEA3WH RGB526PEA4CT RGB526PEA4WH RGB526PEA5WH RGB526PEA6WH RGB528BEA1AD RGB528BEA1CT RGB528BEA1WH RGB528BEA2AD RGB528BEA2CT RGB528BEA2WH RGB528BEA3AD RGB528BEA3CT RGB528BEA3WH RGB528BEA4CT RGB528BEA4WH RGB528BEA5WH RGB528BEA6WH RGB528ET4WW RGB528GEV3AD RGB528GEV3WH RGB528PEA1WW RGB528PEA2WW RGB528PEA5WW RGB528PEH1WW RGB528PEH2WW RGB530BEA1AD RGB530BEA1WH RGB530BEA2AD RGB530BEA2WH RGB530BEA3AD RGB530BEA3WH RGB530BEW2AD RGB530BEW2WH RGB530BEW3AD RGB530BEW3WH RGB532BEA1AD RGB532BEA1CT RGB532BEA1WH RGB532BEA2AD RGB532BEA2CT RGB532BEA2WH RGB532BEA3CT RGB532BEA4AD RGB532BEA4CT RGB532BEA4WH RGB532BEA5AD RGB532BEA5WH RGB532BEA6WH RGB532BEA7WH RGB532BEA8WH RGB532BEW2AD RGB532BEW2WH RGB532BEW3AD RGB532BEW3WH RGB533BEK1BB RGB533BEK2BB RGB533CEH1CC RGB533CEH2CC RGB533CEH3CC RGB533CEH4CC RGB533CEH5CC RGB533WEA1WW RGB533WEA2WW RGB533WEA4WW RGB533WEA5WW RGB533WEA6WW RGB533WEA7WW RGB533WEA8WW RGB533WEH1WW RGB533WEH2WW RGB533WEH3WW RGB533WEH4WW RGB533WEH5WW RGB533WEW2WW RGB533WEW3WW RGB535BEA1AD RGB535BEA1CT RGB535BEA1WH RGB535BEA2AD RGB535BEA2CT RGB535BEA2WH RGB535BEA3CT RGB535BEA4AD RGB535BEA4CT RGB535BEA4WH RGB535BEA5AD RGB535BEA5WH RGB535BEA6WH RGB535BEA7WH RGB535BEA8WH RGB535GEV4AD RGB535GEV4WH RGB535GEV5AD RGB535GEV5WH RGB540SEH1SA RGB540SEH2SA RGB540SEH3SA RGB628BEA1AD RGB628BEA1WH RGB628BEA2AD RGB628BEA2WH RGB628GEV4AD RGB628GEV4WH
